Flat recessed LED luminaire LED IN-Stick H for milled groove, IP44, incl. LED24-plug cable, 113cm, 27.5W 4000K 100°, CRI> 95

Flat LED recessed light LED IN-STICK H for milling groove, IP44, with LED-24 plug cable

The flat LED recessed light LED IN-STICK H is perfect for use in furniture and on the wall. With a size of 113 x 3.4 x 1.3 cm and a color in aluminum and opal, it seamlessly fits into any environment. The light color is neutral white and the color rendering index is 90-100Ra with a color rendering level of 1A.

Technical Details

The operating voltage is 24V= with a constant current of 1150mA. The power consumption is 27.5W with a luminous efficacy of 54lm/W and a luminous flux of 1520lm. The average lamp life is 60000 hours, ensuring a long service life. The installation opening has a rectangular length of 112.5 cm and a width of 3 cm.

Installation and Connection

The LED recessed light is connected via the LED-24 plug system and can be operated with a voltage-controlled LED power supply. The installation is done through recessed mounting and the plug type is also the LED-24 plug system. The protection class is 3 and the ambient temperature should be between -5 and 35°C.

Additional Information

The LED recessed light has an extremely wide beam angle of 100° and is delivered without a light diffuser. The conductor cross-section is 0.21mm2 and the glow wire test according to IEC 60695-2-11 is not available. The energy efficiency class is G and the color temperature is 4000K. The recessed light can be dimmed when using appropriate accessories.

Scope of Delivery and Replacement

The LED recessed light comes with the necessary LED-24 plug cable and the light source is already integrated. The light source is not replaceable, but the high quality ensures a long lifespan. Please note that the recessed light is only suitable for indoor use and has an IP protection rating of 20.
