LED driver TRIAC

LED Driver TRIAC, 35W, 4600lm, IP20

The LED Driver TRIAC from Frisch-Licht with the article number FL-TRUNI.2258TRIAC.ZE offers a power consumption of 35W and a luminous flux of 4600lm. This driver has an average lamp lifespan of 50000 hours and is ideal for use in various environments with an ambient temperature of -25° to +45°C.

Technical Details

The LED Driver TRIAC has an operating voltage of 220-240V~ and has a protection class 2 with IP protection rating IP20. It has a size of 17.23 x 4.4 x 3 cm and a weight of 0.197kg. Accessories such as strain relief are already included in the delivery.

Dimming Function

This LED Driver supports the dimming modes phase cut and phase cut-off, allowing for individual adjustment of brightness. The ripple current is ±5%, ensuring stable and uniform light output. Additionally, the driver is SELV and ENEC certified.

Further Information

The LED Driver TRIAC is compatible with the LED modules ADL 2258MA.4682-6L and ADLQ 2258MA.4682-6L. The maximum cable length to the LED module is 5m. The input voltage is between 220-240V AC and the output voltage is preset between 27-38V. For installation, a circuit breaker B 16A with 7 or a circuit breaker C 16A with 11 is recommended.

Versatile Use

The LED Driver TRIAC is a versatile and reliable choice for various lighting applications. With its high efficiency and durable design, this LED driver is a cost-effective solution for both residential and commercial settings. Upgrade your lighting system with the LED Driver TRIAC today and experience the benefits of energy-efficient and long-lasting illumination.
