under-cabinet luminaire up / down IP20, opal, black 7

Efficient LED Shelf Lighting for Pleasant Illumination

The Up & Down LED shelf light from Hera offers bright yet energy-saving lighting with a power consumption of 7.1 watts. With a warm white color temperature (3000K) and a luminous flux of 760 lumens, it creates a pleasant atmosphere. The fixture is equipped with a single light source and features symmetrical light distribution, ensuring even illumination.

Modern Design and High-Quality Materials

The light impresses with its slim and unobtrusive design, measuring 86 x 1.91 x 1.6 cm (length x width x height). The housing is made of robust aluminum combined with plastic, providing long durability and a high-quality appearance. The surface of the fixture is finished in elegant black with an opal cover, which softly diffuses the light and prevents glare.

Easy Installation and Technical Details

The LED shelf light is designed for surface mounting and has a shallow installation depth of only 1 cm. The rectangular mounting opening is particularly narrow, with a width of 0.36 cm. It operates at a voltage of 24 volts DC (24V=), making installation safe and straightforward. The nominal current is 300 mA, and the LED driver is voltage-controlled, ensuring a stable and reliable light source.

High Light Quality and Safety

With a color rendering index (Ra) of 80 to 89, it provides realistic and natural color representation, making rooms appear vibrant. The fixture complies with photobiological safety level RG0 according to EN 62471, meaning there are no health risks from the emitted light. Color consistency is ensured with an SDCM value of 5, providing uniform light color without visible color deviations.

Reliability and Areas of Application

The LED shelf light is rated IP20 and suitable for indoor use. It operates reliably within ambient temperatures from -5 to 35 degrees Celsius. The extremely wide beam angle of over 80 degrees provides a broad light field and optimal illumination of the area beneath the shelf. With a conductor cross-section of 0.34 mm² and 2 poles, the electrical connection option is clearly defined and user-friendly.
