LED power supply unit POWERLINE PANEL CC, white

High-Quality LED Power Supply from SIGOR

The POWERLINE PANEL CC power supply from SIGOR impresses with its outstanding quality and reliability. With a nominal current of 900mA and a power output of 36 watts, it is ideally designed to supply LED lights. The device features an elegant white design, ensuring discreet integration into various applications. Protection class 2 and IP20 rating provide solid protection against contact and dust.

Efficient and Durable Technology

The power supply is characterized by high efficiency, achieving an efficiency rate of 89% at full load. This means that only a small amount of energy is lost as heat, reducing operating costs and being environmentally friendly. Additionally, the average lamp lifespan of 30,000 hours is very long, ensuring a continuous and stable power supply. The power factor of 0.95 also ensures efficient use of electrical power.

Robust and Compact Design

With dimensions of 11.8 cm in length, 4.2 cm in width, and 2.8 cm in height, the power supply is compact and space-saving. Its low weight of only 85 grams facilitates installation and handling. The operating voltage is 230 volts, and the output voltage is 40 volts DC, guaranteeing a stable and safe supply to the LEDs. The power supply is also designed for an ambient temperature range of -20 to 40 degrees Celsius.

High Durability and Safety

The POWERLINE PANEL CC power supply is rated for up to 50,000 switching cycles, ensuring long and reliable use. The maximum case temperature (Tc) is 75 degrees Celsius, effectively preventing overheating. Protection class 2 and IP20 rating protect the power supply from contact with live parts and provide adequate protection against foreign objects larger than 12.5 mm. This ensures safe operation at all times.

Energy-Efficient Operation with Low Standby Consumption

The power supply consumes only 0.5 watts in standby mode, further contributing to energy savings. The mains frequency range of 50 to 60 hertz allows flexible use in various power grids. Thanks to its stable and efficient design, the POWERLINE PANEL CC power supply is an ideal solution for reliable, durable, and energy-saving power supply of LED lighting.
